This is a post for the EMNLP 2019 paper The Bottom-up Evolution of Representations in the Transformer: A Study with Machine Translation and Language Modeling Objectives.

We look at the evolution of representations of individual tokens in Transformers trained with different training objectives (MT, LM, MLM - BERT-style) from the Information Bottleneck perspective and show, that:
  • LMs gradually forget past when forming predictions about future;
  • for MLMs, the evolution proceeds in two stages of context encoding and token reconstruction;
  • MT representations get refined with context, but less processing is happening.
September 2019


Introduction

Recently, analysis of deep neural networks has been an active topic of research. While previous work mostly used so-called 'probing tasks' and has made some interesting observations (we will mention some of these a bit later), an explanation of the process behind the observed behavior has been lacking.

In our paper, we attempt to explain more generally why such behavior is observed. Instead of measuring the quality of representations obtained from a model on some auxiliary task, we characterize how the learning objective determines the information flow in the model. In particular, we consider how the representations of individual tokens in the Transformer evolve between layers under different learning objectives. We look at this task from the information bottleneck perspective on learning in neural networks.

In addition to a number of interesting results which give insights into internal workings of Transformer trained with different objectives, we try to explain the superior performance of the MLM (BERT-style) objective over the LM one for pretraining.

Tasks: MT, LM, MLM (aka BERT)

We consider three tasks.

Machine Translation (MT)
Given a source sentence and a target sentence , NMT models predict words in the target sentence, word by word, i.e. provide estimates of the conditional distribution .

We train a standard Transformer and then take only it's encoder. In contrast to the other two tasks we describe below, representations from the top layers are not directly used to predict output labels but to encode the information which is then used by the decoder.

Language Modeling (LM)
LMs estimate the probability of a word given the previous words in a sentence: . Formally, the model is trained with inputs and outputs , where is the output label predicted from the final (i.e. top-layer) representation of a token .


Masked Language Modeling (MLM)
The last objective we consider is the MLM objective, which is (most of) the training objective of BERT. In training, 15% of tokens are sampled to be predicted. Each of the sampled tokens is replaced with a special [MASK] token or a random token in 80% and 10% of the time, respectively, and unchanged otherwise.

For a sentence , where token is replaced with , the model receives as input and needs to predict . The label is predicted from the final representation of the token .

What we are interested in,

or How Representations Evolve and the Underlying Process Defining this Evolution

For all models, we fix model hyperparameters, training data, and parameter initialization. The only thing which is different is the training objective.

All three models start from the same representation of a token in a sentence, which consists of an embedding of a token identity and its position. But the way information flows across layers, or the evolution of a token representation, is different depending on the objective. And this is our main interest.

We hypothesize that the training procedure (or, in our notation, task) defines:
  • the nature of changes a token representation undergoes, from layer to layer;
  • the process of interactions and relationships between tokens;
  • the type of information which gets lost and acquired by a token representation in these interactions.
The nature of our work is quite unusual. We are going to have a lot of experiments and we’ll see a lot of results. Despite that these results alone are quite interesting (in terms of methods, things we look at, conclusions we make; to be honest, there is nothing standard in what we do here :) ), the work itself is not about the results. The most important in what we do, as I see it, is we suggest you a point of view, a way of looking at these results. This is something not seen by the naked eye, hidden inside; this is the underlying process which defines not only the results observed in our work but also some previous works.

Our Point of View: Information Bottleneck

TL;DR: the Evolution is in Squeezing Irrelevant Information About Input While Preserving Relevant

We view the evolution from the Information Bottleneck (IB) perspective.
The Information Bottleneck method aims to extract a compressed representation of an input which retains as much as possible information about an output. It maximizes mutual information with the output while penalizing the MI with the input: .

The work by Tishby and Zaslavsky argues that computation in multi-layered networks can be regarded as an evolution towards the theoretical optimum of the IB objective. The network is moving the information about input trough a cascade of layers, and this process is considered as a Markov chain. The bottleneck is in squeezing irrelevant information about input while preserving relevant.

This implies that output defines a partition of input on relevant and irrelevant information and, therefore, defines the information flow in the model. Since the output is different for each of our models, we expect to see different patterns in the information flow.

Information Bottleneck for Token Representations

Not so easy: representations of individual tokens, not the entire input

Now, we will try to look at the evolution of token representations from the Information Bottleneck perspective. We also view every model as learning a function from input X to output Y.

Note that we look into representations of individual tokens, not the entire input. It means that our situation is more complex than we discussed earlier. In our setting, the information retained in a representation of a token is induced due to the two roles it plays:
  • predicting the output label from a current token representation;
  • preserving information necessary to build representations of other tokens.
For example, as shown in the illustration, a language model constructs a representation which is not only useful for predicting an output label, in this case the next token, but also for producing representations of subsequent tokens in a sentence. This is different from the MT setting, where there is no single encoder state from which an output label is predicted.

Mutual Information with input:

LM forgets a lot, MT - less, MLM has context encoding and token reconstruction stages

To illustrate the process of information loss and gain in representations of individual tokens, we first estimate the mutual information between token representations and the input token identity. Since the direct evaluation of mutual information between layers and labels is challenging for large networks, we use an approximation (if you are interested in the details, take a look at the paper). In this experiment, we use MLM as at test time, without masking out tokens.

We see that LM gradually forgets the current input token identity. MT shows a similar behavior, but the decrease is much less sharp. This agrees with our expectations: while LM has to predict next token from the top layer, and therefore is forced to forget not so relevant current token, MT is not forced to do so since nothing is predicted directly and token identity may be useful for translation.

The most interesting and surprising graph is for MLM: first, similarly to other models, the information about the input token is getting lost but then, at two top layers, it gets recovered. We will refer to these phases as context encoding and token reconstruction.

Important note. Whereas such non-monotonous behavior is impossible when analyzing entire layers, in our case, for representations of individual tokens, it suggests that this extra information is obtained from other tokens.

Mutual Information with both input and output:

Information about input is getting lost, information about output is accumulated

Now we’ll come even closer to the Information Bottleneck setting and measure MI with the output label for LM and MLM. In this experiment, we form data for MLM as in training, masking or replacing a fraction of tokens. Then we pick only the examples where input and output are different.

We can see that, as expected, MI with input tokens decreases while MI with output tokens increases. Both LM and MLM are trained to predict a token (next for LM and current for MLM) by encoding input and context information. While in the previous figure we observed monotonic behavior of LM, when looking at the information with both input and output tokens, we can see the two processes, losing information about input and accumulating information about output, for both LM and MLM models. For MLM these processes are more distinct and can be thought of as the context encoding and token prediction (compression/prediction) stages. For MT, since nothing is predicted directly, we see only the encoding stage of this process.

This observation relates also to the findings by Blevins et al, 2018. They show that up to a certain layer the performance of representations obtained from a deep multi-layer RNN LM improves on a constituent labeling task, but then decreases, while for representations obtained from an MT encoder performance continues to improve up to the highest layer. We further support this view with other experiments in the section "What does a layer represent?".

Even though these experiments give insights into processes shaping the representations, direct estimation of mutual information in this setting is challenging and we had to use an approximation. That’s why now we switch to more well-established frameworks.

Analyzing Changes and Influences

How: Compare Different 'Views' on the Same Data

In this part, we also focus on the information flow in the models. The questions we ask include:
  • how much processing is happening in a given layer;
  • which tokens influence other tokens most;
  • which tokens gain most information from other tokens.
We reduce all these questions to a comparison between network representations. In these experiments, we take a lot of data, feed it to a network and get representations from some layer. Altogether, these representations form a ‘view’ of a layer on this data. We gather different ‘views’ on the same data. Then we use projection weighted Canonical Correlation Analysis (PWCCA) to measure the similarity between pairs of such views. (By taking (1-similarity), we get PWCCA distance).

For example, the views can be the same layers in different networks. In this way, we evaluate the distance between tasks. Alternatively, the views can be different layers in the same network. In this way, we evaluate the amount of change between layers for each task.

A coarse-grained view

Distance between tasks: MT and MLM are closer to each other than to LM

As the first step in our analysis, we measure the difference between representations learned for different tasks. For each task, we also measure differences between representations of models trained with the same objective but different random initializations. ("init." lines on the figure).

First, we see that models trained for the same task, but different random initializations, are more similar to each other than models trained with different objectives. This means that PWCCA has passed our 'sanity check': it captures underlying differences in the types of information learned by a model rather than those due to randomness in the training process.

Representations of MT and MLM are closer to each other than to LM's representations. There might be two reasons for this. First, for LM only preceding tokens are in the context, whereas for MT and MLM it is the entire sentence. Second, both MT and MLM focus on a given token, as it either needs to be reconstructed or translated. In contrast, LM produces a representation needed for predicting the next token.

Change between layers

TL;DR: decreasing change for MT, a lot of change for LM, the two stages for MLM

Similarly, we measure the difference between representations of consecutive layers in each model (look at the figure).

When going from bottom to top layers, MT changes its representations less and less. For LM and MLM, there is no such monotonicity. This mirrors our view of LM and especially MLM as evolving through phases of encoding and reconstruction. This evolution requires a stage of losing information not useful to the output, which, in turn, entails large changes in the representations between layers.


Change and Influence of Tokens with Varying Frequency

In the process of encoding, representations of tokens in a sentence interact with each other. In these interactions, on the one hand, they influence other tokens by giving some information. On the other hand, they are influenced by other tokens, which means that their representations consume information (and change themselves).

We now look at the tokens as behaving is these two aspects: influencing others and being influenced by others. We select tokens with some predefined property (e.g., frequency) and investigate how tokens' behavior depends on the value of this property.

Amount of change. We measure the extent of change for a group of tokens as the PWCCA distance between the representations of these tokens for a pair of adjacent layers (n, n+1). This quantifies the amount of information the tokens receive in this layer.

Amount of influence. To measure the influence of a token at n-th layer on other tokens, we measure PWCCA distance between two versions of representations of other tokens in a sentence: first after encoding as usual, second when encoding first n-1 layers as usual and masking out the influencing token at the n-th layer.
Look at the illustration.



Amount of Change: Frequent tokens change more than rare for MT and LM, the two stages for MLM

First, we measure the amount of change, or how much tokens are influenced by others. We see that for MT and LM frequent tokens change a lot more than the rare ones. The only difference in the behavior of these models is that at the top layers of LM the amount of change is roughly the same for all frequencies. We can speculate that this is because top LM layers focus on building the future rather than understanding the past, and, at that stage, token frequency of the last observed token becomes less important.

The behavior for MLM is quite different. The two stages for MLMs could already be seen when measuring mutual information. They are even more pronounced here. The transition from a generalized token representation, formed at the encoding stage, to recreating token identity apparently requires more changes for rare tokens.

Amount of Influence: Rare tokens influence more than frequent

Let’s now measure to what extent tokens influence others.

Generally, rare tokens influence more.
Informally speaking, if you have a lot of information (like rare tokens) you don’t change much, keeping your information, but influence others. Of course, if you are a rare token, you definitely have something to say! On the other hand, if you don’t have much information in yourself (like frequent tokens), you can’t really influence others much, but others change you a lot.

Note this extreme influence of rare tokens on the first layer of MT and for LM. In contrast, rare tokens are not the most influencing ones at the lower layers of MLM.

Extreme Influence of Rare Tokens: Bug or Feature?

We hypothesize that the training procedure of MLM, with masking out some tokens or replacing them with random, teaches the model not to over-rely on these tokens before their context is well understood. To test our hypothesis, we additionally trained MT and LM models with token dropout on the input side: at training time, each token was replaced with a random with probability 10%. As we expected, there is no extreme influence of rare tokens when using this regularization, supporting the above interpretation.

Remember our Story of Heads? The Rare Tokens attention head!

Interestingly, for the MT task The Story of Heads (or our ACL 2019 paper) gives us the exact form how influence of rare tokens is implemented in the MT model. On the first layer, there's the 'rare tokens head': a head pointing to the least frequent tokens in a sentence. While this observation is quite intriguing, results of this work suggest that this is a fancy kind of model overfitting.

What does a layer represent,

or I'll look at your neighbors and will tell who you are

Previously we quantified the amount of information exchanged between tokens. Now, we want to understand what representation in each layer 'focuses' on. We will look at the evolution of the learned feature space and will try to evaluate to what extent a certain property is important for defining a token representation at each layer, or to what extent it is defining for ordering token occurrences in the representation space.

Since the encoding process starts from a representation consisting of token identity and position, first we will track how this information is preserved. Then, we will look at how the contextual information (both past and future) evolves in token representations.

MLM best preserves token identity


To evaluate how token identity is preserved, we
  • take a large number of representations of different tokens;
  • evaluate the proportion of top-k neighbors in the representation space which have the same token identity.

The results are similar to the ones computed with MI estimators! This supports the interpretations we made previously.

To make it more interesting, let us recall the findings by Zhang and Bowman (2018). They show that untrained LSTMs outperform trained ones on the word-identity prediction task. This mirrors our view of the evolution of a token representation as going through compression and prediction stages, where the learning objective defines the process of forgetting information. If a network is not trained, it is not forced to forget input information.

Here is an illustration.
We gathered representations of tokens is, are, were, was from a lot of sentences and visualized their t-sne projections (on the x-axis are layers).
As we go from layer to layer, MT and LM mix representations of these tokens more and more (MT to a lesser extent).
For MLM, 15% of tokens were masked as in training. In the first layer, representations of these masked tokens form a cluster separate from the others, and then they get disambiguated as we move bottom-up across the layers.

MT best preserves token position

Similarly, we evaluate how a token position is preserved, or how important it is for ordering different token occurrences in the representation space. Formally, we
  • take a large number of representations of the same token (for different tokens);
  • for each occurrence, look at the positions of top-k neighbors;
  • evaluate the average position distance.
The results illustrate how the information about the input (in this case, position), potentially not so relevant to the output (e.g., next word for LM), gets gradually dismissed. As expected, encoding input positions is more important for MT, so this effect is more pronounced for LM and MLM.

As an illustration, we visualize t-SNE of different occurrences of the token it, position is in color (the larger the word index the darker its color), on the x-axis are layers. For MT, even on the last layer ordering by position is noticeable.


Lexical and syntactic context of past and future

TL;DR: LM loses past while forming future, MLM accumulates then loses both

In this section, we will look at the two properties: identities of immediate neighbors of a current token and CCG supertag of a current token (CCG supertags encode syntactic context of a token). On the one hand, these properties represent a model's understanding of different types of context: lexical (neighboring tokens identity) and syntactic. On the other, they are especially useful for our analysis because we can split them into information about 'past' and 'future' by taking either left or right neighbor or part of a CCG tag.

The importance of neighboring tokens.
The results support our previous expectation that for LM the importance of a previous token decreases, while information about future token is being formed. For MLM, the importance of neighbors gets higher until the second layer and decreases after. This may reflect stages of context encoding and token reconstruction.

The importance of CCG tags.
As in previous experiments, the importance of CCG tag for MLM degrades at higher layers.

This agrees with the work by Tenney et al, 2019. The authors deal with BERT and observe that for different tasks (e.g., part-of-speech, constituents, dependencies, semantic role labeling, coreference) the contribution of a layer to a task increases up to a certain layer, but then decreases at the top layers. Our work gives insights into the underlying process defining this behavior.

Recall also results by Blevins et al, 2018, who observed monotonic behavior of representations from a deep RNN MT for a constituent labeling prediction task, and non-monotonic for LM, where performance improved up to a certain layer, then decreased.

For LM these results are not really informative since it does not have access to the future. We go further and measure the importance of parts of a CCG tag corresponding to previous and next parts of a sentence. It can be clearly seen that LM first accumulates information about the left part of CCG, understanding the syntactic structure of the past. Then this information gets dismissed while forming information about future.

The figure shows t-SNE of different occurrences of the token is, CCG tag is in color (intensity of a color is a token position, on the x-axis are layers).
One can see that clustering by CCG tag gets preserved at the upper layers of the MT model, but get slightly lost for MLM.

Conclusions

Now, summarizing all our experiments, we can make some general statements about the evolution of representations. Namely,
  • with the LM objective, as you go from bottom to top layers, information about the past gets lost and predictions about the future get formed;
  • for MLMs, representations initially acquire information about the context around the token, partially forgetting the token identity and producing a more generalized token representation; the token identity then gets recreated at the top layer;
  • for MT, though representations get refined with context, less processing is happening and most information about the word type does not get lost.
This provides us with a hypothesis for why the MLM objective may be preferable in the pretraining context to LM. LMs may not be the best choice, because neither information about the current token and its past nor future is represented well: the former since this information gets discarded, the latter since the model does not have access to the future.
